Innovative digital x-ray system for Casting NDT inspection
360° inspection
The Dxbox-C5 is an innovative system with a radio-transparent turntable enabling X-ray inspection of parts from any direction, including through the turntable. Operator intervention during the X-ray sequence is no more needed.
Unique
Dxbox-C5 is one-of-a-kind worldwide and is especially crucial for applications requiring complex parts to be X-rayed from multiple angles to meet all specified standards.
X-ray system digital imaging
Specifications
| X-ray generator | 225 - 320 - 450 kV | 225 - 320 - 450 kV |
| Flat panel detector | Up to 43 x 43 cm | Up to 17 x 17 inches |
| Number of axes | 5 axes | 5 axes |
| Rotative table | Ø 65 cm | Ø 26 inches |
| SDD | 110 cm | 43 inches |
| Max. part diameter | Ø 65 cm | Ø 26 inches |
| Max. part height | 60 cm | 24 inches |
| Max. part weight | 50 kg | 110 lbs |
| System dimensions | 347 x 222 x 248 cm | 137 x 87 x 98 inches |
| System weight | 14 - 20 tons | 15 - 22 U.S tons |
